4×2 Heavy-Duty Cargo Truck Complete Technical Configuration & Parameters

Quantity:
Availability:





Inquire Add to Basket

Product Description

This document fully lists the core basic configurations and detailed technical parameters of the 4×2 heavy-duty commercial cargo truck. Equipped with reliable Weichai power assembly, durable suspension system and large-load carrying structure, the vehicle features strong power output, excellent passability and stable bearing capacity, suitable for long-distance highway transportation, bulk goods haulage and various complex road working conditions, which can meet diversified logistics and engineering transportation demands.

Basic configuration
Engine	WP6.210E32
Gearbox	8 gears (manual)
Cab	Longhead single row
Drive type	4×2
Axle	7T/13T
Tyres	11.00R20 (6+1)
Basic Parameter
Overall Dimensions	7260×2500×2980mm
Container Dimensions	4800×2300×900mm
Displacement	6230ml
Power	155kw
Wheelbase	4600mm
Wheel span	1870/1790mm
GVW	18000kg
Curb weight	6800kg
Approach Angle	24°
Departure Angle	34°
Suspension	Steel plate springs 9/9+6
Fuel Tank Capacity	300L
Fording depth	500mm
Obstacle ground clearance	350mm
Max. Speed	85km/h
Torque	750N·m
Climbing slope	60%

Note: This specification is for reference only, please refer to the actual vehicles. The factory reserves the final right to interpret the specification.
